ROS 2 launch files: a practical tutorial

A launch file is the difference between a robot that starts and a robot that starts the same way every time. Once a project has more than three nodes, typing commands into five terminals stops being a workflow. A launch file records the whole system: nodes, parameters, remaps, namespaces and order.

This tutorial covers ROS 2 Python launch files from the first node to arguments, includes and conditions, with the mistakes that silently start the wrong robot.

What a launch file replaces

The smallest useful launch file

A Python launch file returns a LaunchDescription containing actions. The most common action is a Node. Save this as bringup.launch.py inside a package’s launch folder.

from launch import LaunchDescription
from launch_ros.actions import Node

def generate_launch_description():
    return LaunchDescription([
        Node(
            package='demo_nodes_cpp',
            executable='talker',
            name='talker',
            output='screen',
        ),
        Node(
            package='demo_nodes_cpp',
            executable='listener',
            name='listener',
            output='screen',
        ),
    ])

Run it with ros2 launch my_package bringup.launch.py. The launch system starts both processes, prefixes their output with the node name and stops everything when you press Ctrl+C.

Arguments make one file serve many robots

Arguments turn a launch file into a template. Declare each one with a default, then read it with LaunchConfiguration. This is how the same file starts a simulation or a real robot, or two robots with different namespaces.

from launch import LaunchDescription
from launch.actions import DeclareLaunchArgument
from launch.substitutions import LaunchConfiguration
from launch_ros.actions import Node

def generate_launch_description():
    use_sim_time = LaunchConfiguration('use_sim_time')
    robot_ns = LaunchConfiguration('robot_ns')

    return LaunchDescription([
        DeclareLaunchArgument('use_sim_time', default_value='false'),
        DeclareLaunchArgument('robot_ns', default_value='robot1'),

        Node(
            package='my_robot',
            executable='controller',
            namespace=robot_ns,
            parameters=[{'use_sim_time': use_sim_time}],
            output='screen',
        ),
    ])

Override at run time with ros2 launch my_package bringup.launch.py use_sim_time:=true robot_ns:=robot2. A boolean argument passed as a string is a classic bug: launch substitutions are strings unless a node declares the parameter type. Declare parameter types in the node or use a YAML parameter file.

Parameters belong in YAML

Long parameter lists do not belong in Python. Put them in a YAML file and pass the path to the node. This keeps the launch file readable and lets you version tuning separately for simulation, lab and production.

my_robot:
  ros__parameters:
    wheel_radius: 0.05
    wheel_separation: 0.32
    max_speed: 0.6
    use_sim_time: false

Load it with parameters=['config/robot.yaml'] in the Node action, or with a ParameterFile substitution if the path is computed. The node name in the YAML must match the node name in the launch file, including any namespace.

Remaps and namespaces

A remap renames a topic, service or action at launch time. It is how you connect a generic driver to your robot’s naming convention without editing the driver. A namespace prefixes every name a node creates, which is how two identical robots share one ROS 2 graph.

Node(
    package='my_robot',
    executable='driver',
    namespace='robot1',
    remappings=[('/scan', 'lidar/scan'), ('/cmd_vel', 'cmd_vel')],
)

Watch the leading slash. An absolute name like /scan ignores the namespace, while a relative name like scan becomes /robot1/scan. Mixing the two is the most common reason a node appears to publish nothing.

Include, conditions and order

Large systems compose launch files. Use IncludeLaunchDescription to pull in a driver or a navigation stack, and IfCondition or UnlessCondition to start parts only when an argument says so. A simulation launch file can include the same robot description as the hardware file, with a different controller.

ROS 2 starts actions in the order they appear, but it does not wait for one node to be ready before starting the next. If a node needs the clock or a transform before it can initialise, add a TimerAction delay or an event handler rather than assuming the order is enough.

XML and YAML launch files

ROS 2 also supports XML and YAML launch descriptions. They are easier for simple compositions and for people who prefer configuration to code. Python remains the most flexible option once you need conditions, computed paths or custom events. Pick one convention per repository and stay with it.

Debugging a launch file

• ros2 launch my_package bringup.launch.py --show-args lists every declared argument and its default.
• --print shows the launch description without running it. Useful for checking substitutions.
• Add output='screen' to every node while debugging; the default log file hides the error you need.
• Check the node list with ros2 node list and the graph with ros2 topic list after startup.
• Dump the running parameters with ros2 param dump /node_name to confirm the YAML actually loaded.

Errors you will meet

Related: ROS 2 for beginners, Nav2 tutorial, Gazebo ROS 2 tutorial, SLAM for beginners, Raspberry Pi 5 robot guide.

Launch files start nodes; choosing how they talk is the next decision: topics, services and actions in ROS 2.

A launch file usually loads a robot description too; see building a URDF for ROS 2.

Older tutorials use ROS 1 launch XML; ROS 2 vs ROS 1 explains why the file changed.

Launch files drive lifecycle transitions with event handlers, and the lifecycle nodes tutorial shows the sequencing pattern.

Sources and further reading

• ROS 2 launch tutorials — official examples for Python, XML and YAML launch files.
• ROS 2 parameters — parameter files, types and overrides.
• ROS 2 design documents — launch architecture and composition.
• Nav2 documentation — launching a real navigation stack with parameters and remaps.
