MQTT robot telemetry with ESP32: topics, QoS and code

MQTT is the cheapest way to get robot telemetry off the machine and onto a dashboard. One broker, a few topics, and an ESP32 publishing battery, speed and fault data over Wi-Fi.

This guide covers the topic design, the QoS choices, a working ESP32 publisher, a subscriber that logs to a database, and the Wi-Fi and memory traps that break telemetry in the field.

Why MQTT suits a robot

• Small messages over a small bandwidth link.
• Publish and subscribe, so many dashboards can read one robot.
• A broker decouples the robot from whoever is watching it.
• Last Will and Testament tells you when a robot drops off.
• Retained messages mean a new subscriber sees the last known state immediately.
• Runs comfortably on an ESP32 with a few KB of RAM per connection.

Design the topic tree first

robots/<robot_id>/status
robots/<robot_id>/battery
robots/<robot_id>/velocity
robots/<robot_id>/fault
robots/<robot_id>/cmd/velocity
robots/<robot_id>/cmd/estop

Keep commands and telemetry in separate subtrees. It makes broker access control simple: the dashboard can read everything under the robot, but write only under cmd/.

QoS without overthinking it

QoS 1 can deliver duplicates, so make the receiving handler idempotent. A command with a sequence number that ignores repeats is safer than one that executes twice.

A working ESP32 publisher

The PubSubClient library is the common choice. Connect, publish on a timer, and use a Last Will so the broker marks the robot offline when the link dies.

#include <WiFi.h>
#include <PubSubClient.h>

WiFiClient net;
PubSubClient mqtt(net);
const char* robot = "robot-01";

void connect() {
  while (!mqtt.connected()) {
    if (mqtt.connect(robot, nullptr, nullptr,
        "robots/robot-01/status", 1, true, "offline")) {
      mqtt.publish("robots/robot-01/status", "online", true);
    } else {
      delay(2000);
    }
  }
}

void setup() {
  WiFi.begin("SSID", "PASSWORD");
  mqtt.setServer("192.168.1.50", 1883);
  mqtt.setBufferSize(512);
}

void loop() {
  if (!mqtt.connected()) connect();
  mqtt.loop();
  static unsigned long last = 0;
  if (millis() - last > 2000) {
    last = millis();
    char buf[96];
    snprintf(buf, sizeof(buf),
      "{\"v\":%.1f,\"b\":%d}", 0.42, 87);
    mqtt.publish("robots/robot-01/telemetry", buf);
  }
}

Note the explicit buffer size. The default 256-byte packet limit is the most common reason a JSON payload silently fails to publish.

The broker

Mosquitto on a small VPS or a Raspberry Pi handles a workshop full of robots. Open 1883 only inside your network, and 8883 with TLS if anything crosses the internet.

sudo apt install mosquitto mosquitto-clients
mosquitto_sub -h localhost -t 'robots/#' -v

Create a username and password per robot, and give the dashboard a separate read-only account. An open broker on a factory network is a remote-control hole.

From broker to dashboard

• Node-RED: fastest path to charts and alerts, runs on the same Pi.
• InfluxDB plus Grafana: better for history and long-term trends.
• Home Assistant: useful for small service robots and lab setups.
• A Python subscriber: writes to Postgres when you need custom logic.

A simple Python subscriber that stores every message with a timestamp is often all a first deployment needs. Build the dashboard after the data is reliable.

Field problems and what causes them

What not to put on MQTT

• Safety stop commands over Wi-Fi. Hardwire the E-stop.
• High-rate control loops. Use a local bus or micro-ROS.
• Large images or point clouds. Send a link or a summary.
• Credentials in plain text on port 1883 across the internet.
• Anything you cannot afford to lose without an acknowledgement path.
